Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: Lanke
  • Model Number: Sewage Pump P-6
  • Theory: Centrifugal Pump
  • Structure: Single-stage Pump
  • Usage: Water
  • Power: Electric
  • Standard or Nonstandard: Standard
  • Fuel: Diesel
  • Pressure: High Pressure
  • Application: Sewage, Manicipal,Construction and Sewage Project
  • Function: handling sewage,solid,corrosive liquid,slurries,debris
  • Materia: Cast iron,Dutile iron,Stainless steel
  • Impeller: 2 blades,semi-open
  • Mechanical Seal: oil lubrication,cartridge cemented carbide
  • Suction/Discharge: 6''
  • Certification: CE & ISO9001:2008
  • Operation: Electric Motor,Diesel Engine or Gasoline Engine
  • Solids: 76.6mm Max
  • Feature: High Efficiency and Convenient Operation and Maintenance,High Suction

Packaging & Delivery

Packaging Details: pump is packaged by exporting plywood case or as clients' requirement.

P Series Non Clog Self Priming Sewage Pump, Agricultural Irrigation Water Pump


Product Description



Dear friend ,pls tell me you parameter just like the flow rate ,head ,size or material , or you can tell me the medium+

transfer distance and flow rate . i will recommend the suitable pump for you ,



Main datas



Capacity( flow rate) :  2 ~ 110m3/h

Head  :2~35 m

Speed:550 ~ 2150rpm

Impeller diameter:222.25mm

Pump weight:138kg /205kg

Power:1  ~ 20hp



Advantage :



Big pump body pass 76.2mmsolid ,high suction head 7.6 m

Convenient repair and clean (a person ten minutes)

Removable cover plate ,replaceable wear plate

OEM ,L/C ,TT ,O/A ,D/P,D/A and so on

CE ,TUV .ISO



Name :   P Series Non Clog Self Priming Sewage Pump, Agricultural Irrigation Water Pump



series self-priming non-clog centrifugal trash pump is our latest generation product base on US technology and craftwork. It is designed for economical & trouble-free operation in handling solid-laden liquids and slurries.



Main charactor

1. beautiful shape and fine structure, reliable performance;

2. with strong capacity of self-priming, no need to equip with flap valve;

3. non-clog, and with powerful capacity of passing big solid;

4. The unique lubrication oil mechanical seal cavity makes the performance more reliable.

5. The hole can make sure that stronger sewage can be cleaned quickly when pump is jammed.

6. Special check valve structure can make the pump start quickly next time.

7. When operated, the pump can self-priming with gas and liquid at the same time.

8. Low rotary speed, reliable operation, long useful life, easily maintenance.

9. Advanced pressure protector make pump operate safety.

10. Very competitive price, high quality, small MOQ, fast delivery,OEM required,exporting plywood case.



Features: Solids Handling Impeller, Exclusive Abrasion-Resistant Seal, Removable Cover Plate with Easy-Grip Handle, Replaceable Wear plate, Removable Rotating Assembly.



Application

1. Municipal Project, Sewage Project, Instruction Project;

2. Transportation of the sewage of uptown;

3. Sewage transportation in Hospital, hotel,slaughter house,fish breeding;

4. Classification of municipal sewage treatment factory and concentrate treatment systems engineering;

5. Transportation of the factory and contaminated water;

6. Sewage and deposit of water purifying system;

7. Industrial sewage of light industry,paper mill,textile,food processing plant,chemical industry,electric utility,deep mines,etc.;

8. Wine and sugar industry;



Operation condition

1. The temperature  ≤ 80°C,the density 1.0~1.3*103Kg/m3,PH: 5~9.

2. Max diameter of solid ≤ 76.2mm.

3. Max suction lifts ≤ 3 inches or 7m.

4. solids ≤2%.

5. Max.working pressure and suction head please refer to performance curve and table.



Additional features include

♦  Replaceable Wear Plate

♦  Heavy Duty Suction Flapper

♦  Removable Inspection Cover allows Clean-out, Impeller, Seal and Flapper without disturbing Piping

♦  Semi-Opened Trash Handling Impeller

♦  Pressure Relief Valve

♦  O-Ring Sealed

♦  External, Shimless Impeller/Wear plate Clearance Adjustment

♦  Back Pull-out Cartridge-type Rotating Assembly for Ease of Maintenance

♦  Cartridge Type Mechanical Seal for Ease of Maintenance



Industries Served

♦  Construction

♦  Industrial

♦  Municipal

♦  Agricultural

♦  Mining

♦  Dewatering

♦  Industrial Waste

♦  Sewage

♦  Oil Field

♦  Petrochemical

♦  Paper Mills

♦  Processing



Mounting Configuration

♦  Frame Mounted

♦  Base Mounted Electric Driven

♦  Engine Driven SAE Mounted

♦  Engine Driven Skid or Trailer Packages

♦  Horizontal or Vertical V-Belt Driven



Performance Data

Inlet/Outlet

2''(50mm), 3''(80mm), 4''(100mm), 6''(150mm), 8''(200mm),10''(250mm),12''(300mm)

Impeller Diameter

158.74mm-457.2mm

Rotary Speed

550RPM-2150 RPM

Flow Rates

8m3/h-1275m3/h 20GPM-5500GPM

Head

6m-63m

Horsepower

1HP-125HP

N.W

92KG-998KG

G.W

114KG-1066KG

Solid Passing

20.63mm-76.2mm

Material

cast iron, ductile iron, stainless steel,CD4MCU,aluminum,bronze

Diesel Driving

Water cooled or air cooled

Method of Connection

Self-priming pumps are available as basic units or may be flexcoupled,V-belt driven or engine mounted.

Drive Variation

Cummins, Deutz, Ricardo, Perkins or Chinese Diesel, Electric Motor

Skid Mounted on Trailer

2 wheels or 4 wheels Trailer

Package

Exporting plywood case

Certificate

CE,ISO9001-2008


Product Description
Packaging & Shipping





Our Services



Samply available: 7~10days.
Qty: 1pc, only pump head is provided.
Price: US$100~200
OEM is welcome
OEM expierence: more than 10 years.
Countries: Germany, U.S.A, Spain, Italy, United Kingdom etc
Warranty: the whole pump is guaranteed within 1 year, the pump's spare parts are guranteed for 3 months from the date of delivery.
For more information, please do not hesitate to contact me.

Company Information





FAQ



The information should be including inquiry as following:
1.Pump's flow rate
2.Pump's Head (Pressure)
3.Driven Mode: By electric motor or diesel engine or bare shaft etc
4.Power and rotary speed
5.Suction lift for self priming pump
6.Temperature of liquid if you can provide
Upon the receipt of the pump's parameter, we can send our quotation to you within 24 hours.

Or the condition of pump station would be provided.
